Kirchhoff’s First Law

According to this law in any network of wires carrying currents he algebraic sum of all currents, meeting at a point is zero, or the sum of incoming currents towards any point is equal to the sum of outgoing currents away from that point.

Let I1, I2, I3, I4, I5 and I6 be the currents meeting at junction point O, flowing in the directions of arrow beads marked on the,.

Taking incoming currents as + ve and outgoing currents as – ve according to Kirchhoff’s first law.

I1+I2+I3+I4+I5+I6 = 0
I1+I4+I5+ = I3+I3+I6
